Show me your ICO magnet and sensor mounts for KTM 690
« on: July 16, 2015, 01:04:12 pm »
So the KTM 690 rallye rider does not have the advantage that the KTM 450 rider has, namely that the stock speedo magnet can be used for the ICO since the 690 does not use a speedo magnet and the speedo sensor instead works by counting the bolts that hold the front brake disc and not a magnet.

The only after-market off-the-shelf fix that I can find for this is the Rally-Raid product (http://www.rally-raidproducts.co.uk/navigation-equipment-rallye/ICO-VR-Trip/ico-sensor-magnet-mount-ktm-690) but the problem is that this makes the stock speedo read 20% too high, which I guess isn't a crisis, but if I can avoid it I want to.

Therefore, this is the option I thinking of trying: drill a hole in the rotor to which the brake disc attaches and glue in an EXC speedo magnet (see http://advrider.cz/technika-lc4-rallye-en.php):








Can anyone maybe say if this is a really bad idea, or if it might work? What have other 690 rallye riders used, any help would be much appreciated!

* RALLYE * HARD ENDURO * MTB *

KTM 690 ENDURO-R RALLYE-LITE * 2016 AMAGEZA FINISHER
KTM 300 XC-W * 2015 ROOF OF AFRICA BRONZE FINISHER
KTM Aera Comp 29er


Offline Bluefish

  • Puppy
  • *
  • Bike: KTM 690 Adventure
  • Posts: 32
Re: Show me your ICO magnet and sensor mounts for KTM 690
« Reply #1 on: July 16, 2015, 02:47:14 pm »
Epoxy it (the putty stuff they give with the magnet) into one of the rivet holes that join the 'disk' and the 'rotor'. Worked for me last year and doing so again.


Offline Dwerg

  • Bachelor Dog
  • *****
  • Bike: Triumph 900 Scrambler
    Location: Western Cape
  • Posts: 12,357
  • Thanked: 533 times
  • No vestige of a beginning, no prospect of an end
Re: Show me your ICO magnet and sensor mounts for KTM 690
« Reply #2 on: July 16, 2015, 02:54:47 pm »
Epoxy it (the putty stuff they give with the magnet) into one of the rivet holes that join the 'disk' and the 'rotor'. Worked for me last year and doing so again.

Yup mine is the same
Previous: KTM 690R, 790ADV, 640ADV, 950ADV, 250XCW BMW F650GS Single, F650GS Twin, F800GS, G450X, R50/2 Honda CRF450X, CRF230 x 2, VFR400 NC30, Z50 Mini Trail Yamaha BWS100 x 2, LB80 Chappy


Offline ktmpilot

  • Pack Dog
  • **
  • Bike: KTM 690 Enduro
    Location: Gauteng
  • Posts: 234
Re: Show me your ICO magnet and sensor mounts for KTM 690
« Reply #3 on: July 16, 2015, 03:08:14 pm »
OK thanks gents, I have that putty from the ICO kit, will give that a try right away!
* RALLYE * HARD ENDURO * MTB *

KTM 690 ENDURO-R RALLYE-LITE * 2016 AMAGEZA FINISHER
KTM 300 XC-W * 2015 ROOF OF AFRICA BRONZE FINISHER
KTM Aera Comp 29er


Offline BlueBull2007

  • Caribbean
  • Global Moderator
  • Bachelor Dog
  • ***
  • Bike: AJS (all models)
    Location: Other
  • Posts: 10,569
  • Thanked: 543 times
Re: Show me your ICO magnet and sensor mounts for KTM 690
« Reply #4 on: July 17, 2015, 01:54:00 pm »
BTW if you can, take an extra cable and sensor with you in your box; these items sometimes go AWOL or the cable is damaged - it really sucks if you dont have an ICO to follow for days on end.
Rally nut. What could possibly go wrong?
Living the Rally Dream - Ride Report
Current bike: KTM 350 EXC   Previous bikes:  2010 WR450F, 2006 KTM450EXC,KTM 450RR, BMW800GS, KTM450EXC, BMW650 GS, BMW650 Dakar, and Honda XR250


Offline GJ

  • Race Dog
  • ***
  • Bike: Husqvarna (all models)
    Location: Western Cape
  • Posts: 650
Re: Show me your ICO magnet and sensor mounts for KTM
« Reply #5 on: July 19, 2015, 09:17:52 am »
My 690 het n gat langs die speado sensor vir iso,bosse gaan hom afruk voor die vurk


Offline BlueBull2007

  • Caribbean
  • Global Moderator
  • Bachelor Dog
  • ***
  • Bike: AJS (all models)
    Location: Other
  • Posts: 10,569
  • Thanked: 543 times
Re: Show me your ICO magnet and sensor mounts for KTM 690
« Reply #6 on: July 20, 2015, 10:04:28 pm »
My 690 het n gat langs die speado sensor vir iso,bosse gaan hom afruk voor die vurk

:thumleft:
